Software for Multiple CCTV DVR (works with H.264 DVR)

Do you have a generic H.264 DVR and want free software (CMS H264) for monitoring? If this is your problem, this article is the solution. Here you will find a universal CMS DVR software that works with most DVRs.

I will talk about the operation of the H264 CMS software, teach how you should do the setup for DVRs, NVRs, and IP cameras.

You will also have the opportunity to download the software for free.

This article is very useful to solve the problem for a lot of people that just like you are also looking for a universal CMS DVR software, so please click the buttons below and share with your friends.

To view live and recorded videos from your DVR or IP camera through your computer, you need to use a CMS (Central Monitoring System) software.

The universal CMS DVR software is used for monitoring mixed brands of DVRs, it's usually used by people who have H.264 network DVRs,

There are many DVRs manufactured in China that do not have a brand and often do not even have manual or monitoring software, that's the reason why people start looking for alternative software for non-branded DVRs such as a universal CMS DVR software.

Let's start with a diagram that shows the installation of a DVR on the local network. In this case, it is necessary to configure it using internal IP.

The DVR must be installed with the security cameras and connected to the router and to the computer with the universal CMS DVR software.

In this diagram, I am using as an example an OEM DVR from Hikvision with TVI technology. For other types of DVRs, the concept is the same.

Make sure that your system is connected as shown in the diagram and check if the images are appearing on the local monitor before continuing.

Before configuring the universal CMS DVR software make sure that the DVR network configuration (IP and port) is correct, Check also the local computer.

See in the example below the network configuration for the Hikvision DVR, the IP is 192.168.2.135 the computer is using IP 192.168.2.192 and therefore they are within the same range of network IPs  (192.168.1.1 to 192.168.2.254)

Make sure that DVR is using the correct IP within your network, it doesn't matter if you are using another brand such as Dahua, Swann, etc. The IP configuration principle is the same. So ,find the IP Menu on the DVR.

Obviously, for your particular case, the IPs will be different from the example above, the important thing is that DVR and computer are configured in the same IP network range.

I'm talking about DVR logic ports. On the configuration menu, you will find names like HTTP, RTSP, Server port or HTTPS port.

Note that different brands of DVR can bring other nomenclatures, the important thing is to find the correct port for the application. If you don't what are the ports for your DVR, read the manual or talk to the DVR dealer.

The image below shows the DVR using port 8000. Other DVRs bring port 37777 by default. Just check the menu to make sure what is the port.

Just write down the ports your DVR is using, just in case you need the information later to configure remote viewing.

Before setup, the DVR for the H264 CMS viewing it is important to make sure everything is working properly between the DVR and the computer. Use a web browser to check if the local viewing is working fine.

By viewing the DVR images using the browser, you are making sure that the IP configuration is correct and the network is working before the installation and configuration of the H264 CMS. This step is pretty important.

You will not find an official website with links to the universal CMS DVR software so I have it available right here. Just click the link below:

Click to download

Remember again that it is not easy to find this universal CMS DVR software available in the latest version, so do not forget to share the information with friends. Click the buttons below:

The universal CMS H264 software installation is extremely simple, just click on the icon and follow the step by step, by clicking "Next". At the end of the installation process choose the language you prefer to use.

See the images below (click to enlarge)

The software main screen shows a sidebar on the left side where a tree appears with the icons for the DVRs, NVRs and, IP cameras. You can click on these icons and drag them to the center of the screen to view the images.

At the center, the software shows all the cameras, at the bottom, there is a toolbar with log information such as date, channels, cameras, and users.

The right side menu shows the date, time, CPU usage, PTZ control and a menu for settings, configuration. and log out.

See below the universal CMS DVR software main screen (click to enlarge)

ONVIF is a universal protocol for electronic security devices. To learn more, just read the article: How does the ONVIF work.

The center menu allows you to choose the image layout that will be displayed on the screen, with options for 1, 4, 8, 9, 13, 16, 25, 36, 64 cameras and full screen.

When audio is enabled and configured on the device, you can open the channel to play it. Just click the icon to increase the volume.

The bottom part of the menu shows the date, equipment, channels, connected users and the status of each device.

Initially, to configure the software, it is necessary to open the "Device Manager" menu to add the desired DVRs, NVRs or IPS cameras.

Click add area and choose a name for the desired zone

After creating the zone, click Add Area to add devices such as DVRs, NVRs, or cameras. A new window will open for the configuration.

Note in the following window that there are several options to configure the device, in this case, I am including a Hikvision DVR that has the IP address "192.168.2.135" with port "8000" user "learn" and a password.

Note that at the bottom there is the manufacturer's choice, I chose the ONVIF option instead of Hikvision, because in previous tests it worked better this way (and the DVR is compatible with that protocol).

Note that this procedure adds the DVR that is on the internal network, at the moment I am not adding devices that are on the Internet.

The procedure to add devices that are on the Internet is identical, just follow the same steps as above but use the IP or domain of the equipment that is on the Internet. Obviously, the device must already be previously configured to be accessed remotely over the Internet.

Below is the example of setting up a Dahua DVR, note that the domain is now used to configure because the device is located on the Internet.

After doing all the setup, the universal CMS DVR software will be ready to be used with different DVR brands as shown in the image below.

To have the images displayed on the screen just drag and drop the devices from the trees to the left-hand side of the screen. Note that there is a mix of IP cameras, DVRs and NVRs, including a "fisheye" camera.
